INTEON ProVision 4K digital microscope

INTEON ProVision 4K – 4K Digital Microscope with 360° Angle View Mode

True 4K Resolution • Autofocus • 2D/3D Switching • Measurement Functions • ESD Safe • 360° Angle View Mode

Overview

The INTEON ProVision 4K is a high-performance 4K digital microscope designed for professional use in electronics manufacturing, quality control, and precision inspection tasks. It offers true 4K resolution, fast autofocus, 2D/3D mode switching, and advanced measurement functions in a robust and user-friendly design.

Key Features

True 4K Resolution – 3840 × 2160 @ 60 FPS with 1/1.8" Sony sensor
Fast Autofocus with Auto Edge Detection
Free 2D/3D Switching – easy mode toggle
Built-in Measurement Tools
Photo & Video Recording with split screen comparison
Continuous Zoom: 0.7X – 5.0X optical + up to 230X digital
ESD Safe
Direct USB Flash Drive Storage
Built-in Adjustable LED Ring Light
2D and Angle View

Technical Specifications

			Parameter
			Specification

			Image Quality
			3840 × 2160P @ 60 FPS (True 4K)

			Sensor
			1/1.8 inch Sony Sensor

			Output Interface
			HDMI + UVC-USB 3.0

			Optical Magnification
			0.7X – 5.0X (Continuous Zoom)

			Digital Magnification
			25X – 230X (Adjustable)

			Storage
			Direct USB Flash Drive Storage

			Base
			Metal, 320 × 260 × 20 mm

			Column Height
			280 mm

			Light Source
			Built-in Adjustable LED Ring Light

			Camera Functions
			Auto Focus, Photo & Video Recording, Measurement

Parameter	Specification
Image Quality	3840 × 2160P @ 60 FPS (True 4K)
Sensor	1/1.8 inch Sony Sensor
Output Interface	HDMI + UVC-USB 3.0
Optical Magnification	0.7X – 5.0X (Continuous Zoom)
Digital Magnification	25X – 230X (Adjustable)
Storage	Direct USB Flash Drive Storage
Base	Metal, 320 × 260 × 20 mm
Column Height	280 mm
Light Source	Built-in Adjustable LED Ring Light
Camera Functions	Auto Focus, Photo & Video Recording, Measurement
