The SVII-K100 Stencil Inspection Machine System represents a cutting-edge solution in the realm of solder paste inspection, ensuring the highest quality in stencil printing processes. As an integral part of SMT (Surface Mount Technology), this system is equipped to deliver precise and comprehensive inspection results that are crucial for maintaining the integrity of electronic assemblies. The following summary outlines the product's attributes and functionalities, emphasizing why the SVII-K100 is a must-have for any operation prioritizing precision and reliability.
At the heart of the stencil inspection machine is a robust Operating System, Windows 10, which provides a stable and user-friendly interface. This familiar platform ensures that operators can easily navigate through the various features and settings of the system without extensive training, making the SVII-K100 both accessible and efficient. The choice of Windows 10 also means that the system benefits from the vast array of compatible software tools and support available for this operating system.
The SVII-K100 boasts an advanced Lighting System that is expertly designed to enhance the inspection process. It features a Top Red Coaxial Light that provides uniform illumination across the stencil's surface, allowing for the detection of minute defects that could compromise the printing process. The Bottom lighting comprises a custom White LED Light Source, engineered to deliver optimal clarity and contrast for the inspection of the underside of the stencils. This dual lighting system guarantees that all aspects of the stencil are thoroughly examined, preventing any imperfections from going unnoticed.
What sets the SVII-K100 stencil inspection machine apart is its Inspection Method, which utilizes 3D AOI (Automated Optical Inspection) technology. This advanced approach allows for the three-dimensional inspection of stencils, ensuring that even the most subtle variances in height, shape, and alignment are detected. The 3D AOI capability is pivotal in identifying potential issues that could lead to soldering defects, bridging, or insufficient solder paste volume.
The stencil inspection machine system also excels in terms of resolution. With a remarkable 10μm Resolution, the SVII-K100 is capable of identifying even the smallest inconsistencies and potential faults in the stencil printing process. This high-resolution capacity is vital for today's ever-decreasing component sizes and pitch distances, where even slight deviations can lead to significant problems in the final product.
The Model SVII-K100 is the embodiment of precision engineering, designed to cater to the exacting standards required in stencil inspection. Its robust construction and state-of-the-art features ensure that it is not only capable of delivering exceptional performance but also of integrating seamlessly into any SMT line. The SVII-K100 stencil inspection machine system is a testament to the commitment to quality and efficiency in the electronic assembly industry.
In summary, the SVII-K100 stencil inspection machine system is a sophisticated and reliable solution for any organization that demands the highest standards in stencil printing. With its Windows 10 operating system, innovative lighting system, 3D AOI inspection method, and ultra-high resolution, this machine is poised to revolutionize the inspection process, ensuring flawless stencil printing and ultimately, the quality of the electronic assemblies produced. The SVII-K100 is an investment in precision, efficiency, and reliability, making it an indispensable tool in the field of electronic manufacturing.
| Technical Parameter | Description |
|---|---|
| Inspection Speed | Up To 0.5/s Per FOV |
| Interface | Ethernet/Wifi |
| Field of View | Up To 18.6 mm x 14 mm |
| Dimensions | 1130mm x 1215mm x 1500mm |
| Software | Proprietary Software |
| Model | SVII-K100 |
| Weight | 830kg |
| Lighting System | Top: Red Coaxial Light, Bottom: Custom White LED Light Source |
| Resolution | 10μm |
| Operating System | Windows 10 |
The SVII-K100 stencil inspection machine is an advanced solution designed to meet the rigorous demands of modern electronics manufacturing. Crafted with precision in China, this high-resolution inspection system is meticulously engineered to detect stencil printing defects that can affect the quality of the final product. With a certification of CE, the SVII-K100 stencil inspection machine is compliant with the highest safety and quality standards, making it a trustworthy addition to any production line.
The SVII-K100 is accessible for businesses of all sizes, from small-scale operations to large industrial facilities. The system boasts a remarkable resolution of 10μm, ensuring that even the finest details are captured with exceptional clarity. This high level of detail is critical for identifying potential issues before they lead to costly rework or scrap.
The SVII-K100 stencil inspection machine features a versatile interface that supports both Ethernet and Wifi connections, providing flexibility for integration into various manufacturing environments. The machine's power supply requirements are easily met with a standard 220V AC, 50/60Hz connection, making it a convenient choice for facilities around the globe.
Equipped with a generous field of view of up to 18.6 mm x 14 mm, the Sunmenta SVII-K100 stencil inspection machine can inspect large areas of the stencil quickly and efficiently. This wide field of view, coupled with an impressive inspection speed of up to 0.5/s per FOV, allows for rapid and thorough inspections, minimizing downtime and maintaining high throughput in production lines.
The stencil inspection machine is ideal for use in a range of scenarios, including but not limited to, electronics assembly lines, where precision solder paste printing is critical for the performance of the final product. In high-volume manufacturing, where time is of the essence, the SVII-K100's speedy inspection capability ensures that quality control does not become a bottleneck in the production process.
Overall, the Sunmenta SVII-K100 stencil inspection machine is a highly capable and versatile system that can be applied in various production occasions where stencil printing accuracy is paramount. Its robust design, high-resolution imaging, and fast inspection speeds make it an essential tool for quality assurance in electronics manufacturing and other industries where stencil printing plays a critical role.
Model Number: SVII-K100
Place of Origin: China
Certification: CE
Power Supply: 220V AC, 50/60Hz
Inspection Speed: Up To 0.5/s Per FOV
Operating System: Windows 10
Field Of View: Up To 18.6 Mm X 14 Mm
Interface: Ethernet/Wifi
Installation and Setup: Our technical team provides professional installation and setup services to ensure that your Stencil Inspection Machine is configured correctly for your specific needs. This includes calibration, testing, and initial training for your operators.
Training: We offer detailed training sessions for operators and maintenance personnel. These sessions cover the operation of the machine, software navigation, routine maintenance, and troubleshooting procedures.
Software Updates: Our software is regularly updated to improve functionality, add new features, and enhance user experience. We provide easy-to-follow instructions for software updates to keep your system up-to-date.
Preventive Maintenance: Regular maintenance is key to the longevity and performance of your Stencil Inspection Machine. We provide preventive maintenance guidelines and schedules to help you avoid downtime and extend the life of your equipment.
Remote Support: Should you encounter any issues, our remote support team is ready to assist you. Using the latest remote diagnostics tools, we can troubleshoot and resolve many problems without the need for an on-site visit.
On-site Repair Services: In the event that a problem cannot be resolved remotely, we offer on-site repair services. Our skilled technicians will visit your facility to diagnose and repair the issue promptly.
Replacement Parts: We supply a full range of replacement parts for the Stencil Inspection Machine. All parts are guaranteed to be of the highest quality and are specifically designed for compatibility with your system.
Technical Documentation: A complete set of technical documentation is provided with your Stencil Inspection Machine. This includes user manuals, schematics, parts lists, and maintenance guides to give you full control over the operation and servicing of your equipment.
Your satisfaction and success are important to us. Our goal is to provide you with the support and services you need to keep your Stencil Inspection Machine System performing at its best.
