HIT520 S3 S5 & S7 Screen Printer

HIT 520 S3 / S5 / S7 – High Performance SMT Screen Printer

Automatic Squeegee Pressure • 3D Laser Paste Inspection • Large FOV Camera

Overview

HIT 520 S3 S5 S7 SMT screen printer

The HIT 520 S3 / S5 / S7 series is a high-performance vision screen printer offering excellent print quality, robust design and maximum user convenience. With advanced automation features, it is ideal for high-mix SMT production requiring high reliability and repeatability.

Key Features

  • Automatic Squeegee Pressure Control with precision sensor and self-developed PID system – real-time adjustment and display
  • Visual Offset Correction – compensates PCB expansion/shrinkage using magnified image
  • Adjustable Squeegee with Side Guide – easy control of printing area according to actual PCB size
  • Auto Gripper Tooling – accurate positioning for PCBs with many precision or irregular components
  • Large FOV Scan Camera – fast full PCB scanning and easy mark/PIN setting
  • Automatic Solder Paste Supply with adjustable volume and automatic calculation
  • 3D Laser Solder Paste Scan – real-time monitoring of paste volume on stencil with alerts

Why Choose HIT 520 Series?

  • Superior print quality and process stability
  • Highly automated for reduced operator intervention
  • User-friendly interface with powerful vision system
  • Robust construction for continuous industrial use

Technical Specifications

Parameter HIT520 S3 HIT520 S5 HIT520 S7
Max. PCB size 600 × 500 mm 650 × 610 mm 850 × 610 mm
Min. PCB size 50 × 50 mm
PCB thickness 0.4–6 mm
Max. PCB weight 5 kg 8 kg 10 kg
PCB under clearance 12–25 mm
Stencil frame size 650 × 550 – 736 × 736 mm 650 × 550 – 800 × 800 mm 650 × 550 – 1050 × 900 mm
Print speed 1–300 mm/s
Squeegee pressure 4–20 kg, automatic (PID control)
Squeegee length 350 / 460 / 560 mm or custom; adjustable squeegee optional
Cycle time (200 × 200 mm PCB, excl. printing) 9 s 10 s 12 s
Alignment repeatability ±12.5 µm @ 6σ
Printing repeatability ±25 µm @ 6σ, Cpk ≥ 2
Conveyor 1 segment, one PCB can wait for loading, automatic width
Fiducial camera marks 0.5–3 mm, 2, 3 or 4 marks, automatic search
Stencil cleaning dry, wet, vacuum, air; Y-axis cleaning; vacuum 10–100% adjustable
2D inspection insufficient solder, no solder, bridging; defects from 0.2 mm
3D solder paste check (paste on stencil) option
PCB scan camera FOV 60 × 60 mm, full PCB image scan
Further standard features laser-guided support pin placement, temperature and humidity display, SPI print offset feedback, air blower
Changeover / new product setup 5 min / 10 min
Air supply 4–6 kg/cm²
Power supply 220 V ±10%, single phase, max. 1 kW, 50/60 Hz
Machine weight approx. 1000 kg approx. 1050 kg approx. 1100 kg
Dimensions (L × W × H) 1423 × 1574 × 1450 mm 1543 × 1652 × 1450 mm 1744 × 1652 × 1450 mm
Options air conditioning, PCB / stage and stencil vacuum, auto gripper tooling, automatic solder paste supply, 3D solder paste check, SECS/GEM, Hermes

Source: HIT brochure (see Downloads).
